As more developers work within distributed environments, tools like Kubernetes have become central to keeping application components standardized across dynamic build and production environments. With the increasing complexity of application ecosystems and the growing popularity of Kuberbetes, tools that help manage resources within Kubernetes clusters have become essential.
Helm is an open-source package manager for Kubernetes that simplifies the process of deploying and upgrading applications on a Kubernetes cluster, while also providing a way to find and share ready-to-install applications that are packaged as Kubernetes Charts.
In this tutorial, we’ll use Helm for setting up WordPress on top of a Kubernetes cluster, in order to create a highly-available website. In addition to leveraging the intrinsic scalability and high availability aspects of Kubernetes, this setup will help keeping WordPress secure by providing simplified upgrade and rollback workflows via Helm.
We’ll be using an external MySQL server in order to abstract the database component, since it can be part of a separate cluster or managed service for extended availability. After completing the steps described in this tutorial, you will have a fully functional WordPress installation within a containerized cluster environment managed by Kubernetes.
In order to complete this guide, you will need the following available to you:
Before moving on, make sure you’re able to log into your MySQL server, and that you have connectivity to your Kubernetes cluster. In case you have multiple clusters set up in your
kubectl config file, you should make sure that you’re connected to the correct cluster by running the following command from your local machine or development server:
This is an example output:
CURRENT NAME CLUSTER AUTHINFO NAMESPACE * do-sfo2-wordpress-cluster do-sfo2-wordpress-cluster do-sfo2-wordpress-cluster-admin minikube minikube minikube
The asterisk sign (*) indicates which cluster is currently the default context. In case you need to change the current context, run:
You should now be ready to follow the rest of the guide.
Step 1 – Configuring MySQL
First, we’ll create a dedicated MySQL user and a database for WordPress, allowing connections from external hosts. This is necessary because our WordPress installation will live on a separate server inside the Kubernetes cluster. In case you already have a dedicated MySQL user and database set up for WordPress, you can skip to the next step.
From the MySQL server, log into MySQL with the following command:
You will be prompted to provide the password you set up for the root MySQL account when you first installed the software. After logging in, MySQL will give you a command prompt you can use to create the database and user we need for WordPress.
Note: For this tutorial, we’ll be creating a database named and a user named
wordpress_user , identified by the password . Please note that these are insecure example values, and you should modify them accordingly throughout this guide.
To create the database, you can use the following statement:
Now, let’s create a dedicated MySQL user for this database:
wordpress_user was created, but it doesn’t have any access permissions yet. The following command will give this user admin access (all privileges) to the wordpress database from both local and external networks:
To update the internal MySQL tables that manage access permissions, use the following statement:
Now you can exit the MySQL client with:
To test that the changes were successful, you can log into the MySQL command-line client again, this time using the new account
wordpress_user to authenticate:
You should use the same password you provided when creating this MySQL user with the
CREATE_USER statement. To confirm your new user has access to the database, you can use the following statement:
The following output is expected:
+--------------------+ | Database | +--------------------+ | information_schema | | wordpress | +--------------------+ 2 rows in set (0.03 sec)
After confirming the database is included in the results, you can exit the MySQL command-line client with:
You now have a dedicated MySQL database for WordPress, and valid access credentials to use within it. Because our WordPress installation will live on a separate server, we still need to edit our MySQL configuration to allow connections coming from external hosts.
While still on your MySQL server, open the file
/etc/mysql/mysql.conf.d/mysqld.cnf using your command-line editor of choice:
bind-address setting within this file. By default, MySQL listens only on
127.0.0.1 (localhost). In order to accept connections from external hosts, we need to change this value to
0.0.0.0. This is how your
bind-address configuration should look:
# Instead of skip-networking the default is now to listen only on # localhost which is more compatible and is not less secure. bind-address = 0.0.0.0
When you’re done making these changes, save and close the file. You’ll need to restart MySQL with the following command:
To test if you’re able to connect remotely, run the following command from your local machine or development server:
Remember to change
mysql_server_ip to your MySQL server IP address or hostname. If you’re able to connect without errors, you are now ready to proceed to the next step.
Step 2 – Installing WordPress
Now that we have the necessary information to connect to the MySQL database, we can go ahead and install WordPress using Helm.
By default, the WordPress chart installs MariaDB on a separate pod inside the cluster and uses it as the WordPress database. We want to disable this behavior and configure WordPress to use an external MySQL database. This and other configuration options (such as the default WordPress admin user and password) can be set at installation time, either via command-line parameters or via a separate YAML configuration file.
In order to keep things organized and easily extendable, we are going to use a configuration file.
From your local machine or development server, create a new directory for your project settings and navigate into it:
Next, create a file named
values.yaml, using your text editor of choice:
Within this file, we need to set up a few variables that will define how WordPress connects to the database, as well as some basic information about your site and the initial admin user for logging into WordPress when the installation is complete.
We’ll base our configuration on the default
values.yaml file from the WordPress Helm chart. The Blog/Site Info section contains general options for your WordPress blog, such as the name of the blog and the initial user credentials. The Database Settings section of this file contains the settings for connecting to the remote MySQL server. MariaDB is disabled in the final section.
Copy the following contents into your
values.yaml file, replacing the highlighted values with your custom values:
## Blog/Site Info wordpressUsername: sammy wordpressPassword: password wordpressEmail: firstname.lastname@example.org wordpressFirstName: Sammy wordpressLastName: the Shark wordpressBlogName: Sammy's Blog! ## Database Settings externalDatabase: host: mysql_server_ip user: wordpress_user password: password database: wordpress ## Disabling MariaDB mariadb: enabled: false
We have just configured the following options:
- wordpressUsername: WordPress user’s login.
- wordpressPassword: WordPress user’s password.
- wordpressEmail: WordPress user’s email.
- wordpressFirstName: WordPress user’s first name.
- wordpressLastName: WordPress user’s last name.
- wordpressBlogName: Name of the Site or Blog.
- host: MySQL server IP address or hostname.
- user: MySQL user.
- password: MySQL password.
- database: MySQL database name.
When you’re done editing, save the file and exit the editor.
Now that we have all settings in place, it is time to execute
helm to install WordPress. The following command tells
helm to install the most recent stable release of the WordPress chart under the name , using
values.yaml as configuration file:
You should get output similar to the following:
NAME: myblog LAST DEPLOYED: Fri Jan 25 20:24:10 2019 NAMESPACE: default STATUS: DEPLOYED RESOURCES: ==> v1/Deployment NAME READY UP-TO-DATE AVAILABLE AGE myblog-wordpress 0/1 1 0 1s ==> v1/PersistentVolumeClaim NAME STATUS VOLUME CAPACITY ACCESS MODES STORAGECLASS AGE myblog-wordpress Pending do-block-storage 1s ==> v1/Pod(related) NAME READY STATUS RESTARTS AGE myblog-wordpress-5965f49485-8zfl7 0/1 Pending 0 1s ==> v1/Secret NAME TYPE DATA AGE myblog-externaldb Opaque 1 1s myblog-wordpress Opaque 1 1s ==> v1/Service NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE myblog-wordpress LoadBalancer 10.245.144.79 <pending> 80:31403/TCP,443:30879/TCP 1s (...)
After the installation is finished, a service named myblog-wordpress is created within your Kubernetes cluster, but it may take a few minutes before the container is ready and the
External-IP information is available. To check the status of this service and retrieve its external IP address, run:
You should get output similar to the following:
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE kubernetes ClusterIP 10.245.0.1 <none> 443/TCP 20h myblog-wordpress LoadBalancer 10.245.144.79 203.0.113.110 80:31403/TCP,443:30879/TCP 3m40s
This command gives you detailed information about services running on your cluster, including name and type of the service, as well as IP addresses used by these services. As you can see from the output, the WordPress installation is being served as
myblog-wordpress on the external IP address
Note: In case you are using
minikube to test this setup, you’ll need to run
minikube service myblog-wordpress in order to expose the container web server so that you can access it from your browser.
Your WordPress installation is now operational. To access the admin interface, use the public IP address obtained from the output of
kubectl get services, followed by
/wp-admin in your web browser:
You should use the credentials defined in your
values.yaml file to log in and start configuring your WordPress site.
Step 3 – Upgrading WordPress
Because of its popularity, WordPress is often a target for malicious exploitation, so it’s important to keep it updated. We can upgrade Helm releases with the command
To list all of your current releases, run the following command from your local machine or development server:
You should get output similar to this:
NAME REVISION UPDATED STATUS CHART APP VERSION NAMESPACE myblog 1 Fri Jan 25 20:24:10 2019 DEPLOYED wordpress-5.1.2 5.0.3 default
As you can see from the output, our current WordPress version is
5.0.3 (app version), while the chart version is
5.1.2. If you want to upgrade a release to a newer version of a chart, first update your Helm repositories with:
You can expect the following output:
Hang tight while we grab the latest from your chart repositories... ...Skip local chart repository ...Successfully got an update from the "stable" chart repository Update Complete. ⎈ Happy Helming!⎈
Now you can check if there’s a newer version of the WordPress chart available with:
You should see output similar to this:
apiVersion: v1 appVersion: 5.1.1 description: Web publishing platform for building blogs and websites. engine: gotpl home: http://www.wordpress.com/ icon: https://bitnami.com/assets/stacks/wordpress/img/wordpress-stack-220x234.png keywords: - wordpress - cms - blog - http - web - application - php maintainers: - email: email@example.com name: Bitnami name: wordpress sources: - https://github.com/bitnami/bitnami-docker-wordpress version: 5.9.0
As you can see from the output, there’s a new chart available (version 5.9.0) with WordPress 5.1.1 (app version). Whenever you want to upgrade your WordPress release to the latest WordPress chart, you should run:
This command will produce output very similar to the output produced by
helm install. It is important to provide the same configuration file we used when installing the WordPress chart for the first time, as it contains the custom database settings we defined for our setup.
Now, if you run
helm list again, you should see updated information about your release:
NAME REVISION UPDATED STATUS CHART APP VERSION NAMESPACE myblog 2 Fri May 3 14:51:20 2019 DEPLOYED wordpress-5.9.0 5.1.1 default
You have successfully upgraded your WordPress to the latest version of the WordPress chart.
Rolling Back a Release
Each time you upgrade a release, a new of that release is created by Helm. A revision sets a fixed checkpoint to where you can come back if things don’t work as expected. It is similar to a commit in Git, because it creates a history of changes that can be compared and reverted. If something goes wrong during the upgrade process, you can always rollback to a previous revision of a given Helm release with the
helm rollback command:
For instance, if we want to undo the upgrade and rollback our WordPress release to its first version, we would use:
This would rollback the WordPress installation to its first release. You should see the following output, indicating that the rollback was successful:
Rollback was a success! Happy Helming!
helm list again should now indicate that WordPress was downgraded back to 5.0.3, chart version 5.1.2:
NAME REVISION UPDATED STATUS CHART APP VERSION NAMESPACE myblog 3 Mon Jan 28 22:02:42 2019 DEPLOYED wordpress-5.1.2 5.0.3 default
Notice that rolling back a release will actually create a new revision, based on the target revision of the roll-back. Our WordPress release named
myblog now is at revision number three, which was based on revision number one.
In this guide, we installed WordPress with an external MySQL server on a Kubernetes cluster using the command-line tool Helm. We also learned how to upgrade a WordPress release to a new chart version, and how to rollback a release if something goes wrong throughout the upgrade process.
As additional steps, you might consider setting up Nginx Ingress with Cert-Manager in order to enable name-based virtual hosting and to configure an SSL certificate for your WordPress site. You should also check the recommended production settings for the WordPress chart we used in this guide.
If you want to learn more about Kubernetes and Helm, please check out the Kubernetes section of our community page.
